TR-Mount:

TILE REPLACEMENT FLASHING
AND ADJUSTABLE BASE

ELIMINATES THE NEED FOR CUTTING, DRILLING, OR GRINDING TILES

The TR-Mount is a rail-based solar attachment solution designed for mounting solar PV on new or existing (retrofit) tile roofs. The TR-Mount is available in Flat, S, and W-shaped tile profiles. This popular system replaces the complete tile located directly above the mount, eliminating the need for cutting, drilling, or grinding of tiles. One universal-sized base mount fits all three tile profiles and features built-in deck-level flashing on all four sides. Simply combine the base with the appropriate flashing kit and slide the post into the track on the base to align it with the hole in the top flashing. Adjustability and versatility make the TR-Mount a quick and easy installation.

Roof Type Icon

Tile

Racking Type Icon

Rail-Based

Attachement Type Icon

strucTURAL

ELIMINATES THE NEED FOR CUTTING, DRILLING, OR GRINDING TILES

The TR-Mount is a rail-based solar attachment solution designed for mounting solar PV on new or existing (retrofit) tile roofs. The TR-Mount is available in Flat, S, and W-shaped tile profiles. This popular system replaces the complete tile located directly above the mount, eliminating the need for cutting, drilling, or grinding of tiles. One universal-sized base mount fits all three tile profiles and features built-in deck-level flashing on all four sides. Simply combine the base with the appropriate flashing kit and slide the post into the track on the base to align it with the hole in the top flashing. Adjustability and versatility make the TR-Mount a quick and easy installation.

Features & Benefits

  • Replaces a complete tile, extra tile can be used to replace broken tiles
  • Two attachment points for optimal pullout values
  • Utilizes patented Elevated Water Seal technology for optimal waterproofing
  • Configurations available for Flat, S, and W shaped tile profiles
